224nF Metallized Film Capacitors 630VDC 15MM Pitch

Name: 224nF Metallized Film Capacitors 630VDC 15MM Pitch
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB28-224J630V-15RN-1U

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

PLACE OF ORIGIN : GUANGDONG, CHINA

TYPE : polypropylene film capacitor

MATERIAL : Polypropylene Film

OPERATION TEMPERATURE : -40 ℃～85℃, Tmax+105℃

MODEL : CBB28-224J630V-15RN-1U

COLOR : Red

DIMENSION : 26MM *20MM*12MM

TOLERANCE : ±5%;±10%;±20%

ENCAPSULATION : plastic package, Sealed with epoxy resin

RATED DC VOLTAGE : 630VDC

CAPACITANCE : 224nF

PITCH : 15MM

SUPPLIER TYPE : ORIGINAL MANUFACTURER

APPLICATION : Suitable for filtering, coupling, bypass, temperature compensation, step-down circuit, timing circuit, industrial instrument, and automatic control system

Terminals : Clip

CHARACTERISTICS : Small case size,long life,high reliability

OEM/ODM : OEM/ODM

Contact Now

224nF Metallized Film Capacitors 630VDC 15MM Pitch Hot Sale

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃, Tmax 105℃
Capacity Range	0.01uf-2.2uf
Rated Voltage	100VDC,250VDC,400VDC,630VDC
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.6Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 100VDC;25℃ ±5℃,60s

Application

Our products are widely used for lighting industry, audio industry ,automation industry,
power supply,telecommunication industry and the household appliance.

Features

Non-inductive, epoxy dip coated, high moisture resistance.
Dissipation factor is normally low and it is stable against high frequency and change of temperature.
Remcommended for high-frequency circuits like s-curve compensating circuit.
High reliability because of its excellent Self-Healing performance.
